On the meter, enable Bluetooth mode. Refer to the user documentation for
the meter for information on how to do this.
3
On the meter, choose the quantity that you want to use (voltage, current,
resistance, etc.). Refer to the user documentation for the meter for informa-
tion on how to do this.
Results from the meter will now automatically be displayed in the result table
in the top left corner of the infrared camera screen.
4
Do one of the following:
■
To preview an image, push the Preview/Save button. At this stage, you
can add additional values. To do so, take a new measurement with the
meter and select Add on the infrared camera screen.
■
To save an image without previewing, push and hold down the Pre-
view/Save button.
■
(Dependent on camera model) To add a value to a recalled image, turn
on the meter after you have recalled the image, then select Add on the
infrared camera screen. A maximum of eight values can be added, but
note that some values are broken into two lines.
5
Publ. No. T559597 Rev. a554 – ENGLISH (EN) – September 27, 2011 51
18 – Fetching data from external Extech meters
