FLIR Raymarine CAM220IP User Manual

2.1Documentinformation
Thisdocumentcontainsimportantinformation
relatedtotheinstallationofyourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthe
necessaryequipment;
•installandconnectyourproductaspartofawider
systemofconnectedmarineelectronics;
•troubleshootproblemsandobtaintechnical
supportifrequired.
ThisandotherRaymarineproductdocuments
areavailabletodownloadinPDFformatfrom
www.raymarine.com.
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
PartnumberNameDescription
E70347
CAM220IP
EyeballIP
camera
Documentillustrations
Yourproductmaydifferslightlyfromthatshown
intheillustrationsinthisdocument,dependingon
productvariantanddateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
Productdocumentation
Thefollowingdocumentationisapplicabletoyour
product:
DescriptionPartnumber
CAM220IPEyeballCameraInstallation
instructions
InstallationofaCAM220IPandconnectionto
awidersystemofmarineelectronics.
87268
CAM220IPsurfacemountingtemplate
MountingdiagramformountingaCAM220IP.
87269
LighthouseMFDOperationInstructions
DetailstheoperationoftheCamera
applicationforaSeries,cSeries,eSeries,
andeSSeriesmultifunctiondisplays.
81360
gSSeriesInstallationandoperation
instructions
IncludesdetailsforoperationoftheCamera
applicationonagSSeriesMFD.
81344
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,
refertothedocumentationthataccompaniesyour
display.
2.2Productoverview
CAM220IP
TheCAM220IPisanInfraredilluminated(I
2
)eyeball
IPcamerawithbothdayandnightvision.In
conjunctionwithacompatiblemultifunctiondisplay
(MFD),thecameraprovidesahigh-denitionimage
whichcanbeviewedorrecordedforlaterplayback.
D12979-1
Thecamerahasthefollowingfeatures:
•2megapixel1/2.8"SONYprogressivescan
CMOSimagesensorforexcellentimagequality
(Exmor)
•3.6mmwide-anglemegapixelboardlens
•20mI
2
beamdistance
•FieldofView(Horizontal=51.0°/Vertical=93.0°
±3°)
•Multi-streamingofH.264andMJPEG
•FullHD(supportsimageresolutionsupto1920x
1080(1080p),at30fps)
•12Vdcpower
•Class2PoEdevice(IEEE802.3af)
ThecameracanalsobeconnectedtoaPCwhich
enablesuseofthebuilt-inwebinterfacetoaccess
additionalfeatures.Theseadditionalfeaturescan
onlybesetorusedviaaconnectedPC.
Approximaterecordtimes
TheapproximaterecordtimesaredependantonIP
cameraresolutionandsettings,lightingconditions
andavailablestoragespace.
ARaymarine
®
CAM220IP,settofactorydefault
settingscanrecordatanapproximaterateof22.5
MBperminute;allowingupto44minutesofrecord
timeper1GBofavailablestoragespace.
12
CAM220IP
