3.5Typicalsystems
Note:Forinformationonhowtoconnectthe
product,refertotheChapter4Cablesand
connectionssection.Forinformationonavailable
cablesandaccessories,refertotheChapter11
Sparesandaccessoriessection.
•Basicmultifunctiondisplay(MFD)system:
Youcanconnecttheproductdirectlytoa
multifunctiondisplayusingthesuppliedRJ45
coupler,andanadditionaladaptorcable(referto
the4.5Networkconnectionsectionfordetails).If
youareconnectingtheproducttoana,c,e,or
eSSeriesMFD,thecamerarequiresaseparate
powersource,eitherconnectingdirectlytoyour
vessel’s12Vdcpowersupply,orusingaPower
overEthernet(PoE)injector(refertothe4.4
Powerconnectionsectionfordetails).Ifyouare
connectingtheproducttoagSSeriesMFD,
thecameracanbesuppliedPoEbythedisplay,
providedthedisplayhasthenecessaryremaining
PoEallocation.RefertothegSSeriesinstallation
andoperationinstructionsfordetailsonPoE
allocation,andalsotothe4.4Powerconnection
section.
•Multiplecamerasystem:
YoucanuseaRaymarinenetworkswitchto
connectmultiplecamerastoasingleMFD.Each
camerarequiresaseparatepowersupply,unless
theswitchiscapableofprovidingPoE,orifthe
cameraisconnecteddirectlytoagSSeries
MFDsupplyingPoE.Refertothe4.5Network
connectionand4.4Powerconnectionsections
fordetails.
•PC/laptopsystem:
YoucanconnecttheproducttoaPCorlaptop
computer,directlyviathecomputer’sEthernet
connector,orindirectlyviaaRaymarinenetwork
switch.Refertothe4.5Networkconnection
sectionfordetails.WhenconnectedtoaPCor
laptopcomputer,youcanaccesstheproduct’s
built-inwebinterface.
3.6Warningsandcautions
Important:Beforeproceeding,ensurethatyou
havereadandunderstoodthewarningsand
cautionsprovidedintheChapter1Important
informationsectionofthisdocument.
16CAM220IP
