STRADA PAL – MAINTENANCE MANUAL
94/149
8.4.2 Replacing the Datapack / Neopsdata board
The collections and data backups must be performed before any embedded software
updates, Neopsdata replacement or battery replacement (see specific chapter).
If not performed, all the data stored on the Neopsdata will be lost.
8.4.2.1 Preliminary operations
A. Open the maintenance door
B. Turn off the terminal
8.4.2.2 Replacement
A. Remove the main board
B. Slide the Datapack board to remove it from its location on the main board.
Replacing the Datapack board
8.4.2.3 Installation
A. Perform the previous steps in reverse, being careful with the assembly direction.
8.4.2.4 Configuration
A. Perform the initialisation procedure of the terminal (refer to the installation guide) to
download the customisation of the terminal.
8.4.2.5 End of procedure
A. Turn on the terminal
B. Close the maintenance door
