Fluidwell E119-P Operation Manual

Page 49
FW-E115-P-M_v0203_03_EN.docx
TECHNICAL SPECIFICATION
Display
Type
High intensity numeric and alphanumeric LCD, UV-resistant, with bright backlight. Intensity
can be adjusted via the keypad.
When battery powered, the backlight is only operational after a keypad touch to extend the
battery lifetime.
Dimensions
Ø 65 x 45mm (2.56” x 1.77”).
Digits
Seven 12mm (0.47”) and eleven 7mm (0.28”). Various symbols and measuring units.
Refresh rate
User definable: 8 times/sec – 30 secs.
Speedometer
To indicate the actual flow rate, the bargraph runs from 0 to 100% in 20 blocks, each block is 5%.
Enclosures
General
Sealing
Control Keys
Rating
Aluminum or stainless steel EX-d enclosure with glass window.
Silicone.
Three optical keys with operation through the glass front window.
IP66 / 67 / TYPE 4X / TYPE 7 / TYPE 9.
Type HA_
Dimensions
Weight
Die-cast aluminum EX d enclosure.
112 x 133 x 148mm (4.41” x 5.24” x 5.83”) – W x H x D.
1300 gr.
Type HS_
Dimensions
Weight
Stainless steel 316L Ex d enclosure.
112 x 133 x 148mm (4.41” x 5.24” x 5.83”) – W x H x D.
3600 gr.
Entry thread
H_A
H_B
H_C
2 x ¾”NPT / 1 x 1”NPT
3 x ¾”NPT
2 x ½”NPT / 1 x 1”NPT
H_D
H_G
H_H
2 x ½”NPT / 1 x ¾”NPT
2 x M20 / 1 x M25
3 x M25
Operating temperature
Ambient
-40°C to +70°C (-40°F to +158°F).
Power requirements
Type PB
Long life Lithium battery – life-time depends upon settings and configuration – up to approx. 3 years
The battery can power the backlight for a short time after a keypad touch but cannot power the
relay output (OR) or the real sensor supply (Terminal P3).
Type PD
9 – 27V DC. Consumption max. 4.5W (sensor excitation included).
In combination with relay output (type OR): 24-27V DC.
Type PX
9 – 27V DC. Consumption max. 3W.
Type AH
Loop powered, analog output. 11 – 27V DC, Min. 2mA.
Consumption max. 675mW (25mA @ 27VDC).
The loop powered analog output cannot power the backlight, mechanical relay output (OR) or
the real sensor supply (Terminal P3).
Sensor excitation
Type AH/PB/PX
Terminal S3: 3V DC for pulse signals and 1.2V DC for coil pick-up, I
out
max. 100μA.
This is not a real sensor supply. Only suitable for sensors with a very low power consumption
like coils (sine wave) and reed-switches.
Type PD
Terminal P3 : 8.2 / 12 / 24V DC
• 8.2V DC, I
out
max. 20mA.
• 12V DC, I
out
max. 30mA.
• 24V DC, I
out
max. 75mA (this voltage varies depending on the input supply voltage)
Terminal connections
Type
Removable plug-in terminal strip.
Wire max. 1.5 mm
2
and 2.5 mm
2.
Data protection
Type
EEPROM backup of all settings.
Backup of running totals every minute. Data retention at least 10 years.
Password
Configuration settings can be password protected.
