Fluidwell E119-P Operation Manual

Page 50
FW-E115-P-M_v0203_03_EN.docx
Hazardous area
ATEX
Gas : II 2 G Ex d IIC T6 Gb.
Dust : II 2 D Ex tb IIIC T85°C Db.
IECEx
Gas : Ex d IIC T6 Gb.
Dust : Ex tb IIIC T85°C Db.
CSA c-us
Class I, Division 1, Grps A, B, C, D
Class II/III, Division 1, Grps E, F, G
Class I, Zone 1, Aex d IIC T6/T5 Gb
Zone 21, Aex tb IIIC T85°C/T100°C Db
FM
Class I, Division 1, Grps A, B, C, D
Class II/III, Division 1, Grps E, F, G
Class I, Zone 1, Aex d IIC T6/T5 Gb
Zone 21, Aex tb IIIC T85°C/T100°C Db
Directives and Standards
EMC
EN 61326-1; FCC 47 CFR part 15
LVD
EN/IEC 61010-1
ATEX / IECEx
EN/IEC 60079-0; EN/IEC 60079-1; EN/IEC 60079-31
CSA
CSA 22.2 No. 25, CSA 22.2 No. 30
FM
FM3600; FM3615; FM3616; FM3810
RoHS
EN 50581
IP & TYPE
EN 60529; NEMA 250
Input
Flowmeter
Type P
Dual flowmeter input: Coil / sine wave (COIL-HI: 20mVpp or COIL-LO: 90mVpp sensitivity
selectable), NPN, PNP, reed switch, NAMUR, active pulse signals 8 or 24V DC.
Frequency
Minimum 0Hz - maximum 10kHz for total and flow rate. Maximum frequency depends on
signal type and internal low-pass filter. E.g. reed switch with low-pass filter: max. frequency
120Hz.
K-Factor
0.000010 - 9,999,999 with variable decimal position.
Low-pass filter
Available for all pulse signals.
Option ZF
Coil sensitivity 10mVpp.
Option ZG
Coil sensitivity 5mVpp.
Reset total
General
Terminal input to reset total remotely or to lock the “clear total” button.
Type IB
Internally pulled-up switch contact - NPN.
Duration
Minimum pulse duration 100msec.
Output
Digital output
General
Transmitting scaled accumulated total.(positive and negative) or input pulse retransmission
Frequency
Scaled: Output D1-D2: max. 500Hz.
Output D5-D6: max. 4Hz, recommended use below 0.5Hz.
Pulse length user definable between 1msec up to 10 seconds.
Retransmission: Minimum pulse duration: 50μs, square wave output based on frequency of
(sine wave or coil) input signal
Type OT
Two passive transistor outputs (NPN) - not isolated. 300mA - 50V @ 25°C.
Type OR
Two isolated electro-mechanical relay outputs (NO).
Maximum resistive load: 2A @ 250V AC / 30V DC.
Maximum inductive load: 0,5A (pilot duty applications).
• Requires 24 - 27V DC and supplied via P5 - P6.
• Type OT remains available.
• Not used in pulse retransmission mode.
Analog output
General
Transmitting differential flowrate, forward flow or reverse flow
Type AH
Galvanically isolated, loop powered 4 - 20mA output.
Supply voltage
10V (lift-off voltage) – 27V DC
Max load
700 ohm @ 24V DC (24V - 10V / 20mA)
Accuracy
12 bit. Error 0.03% @ 20°C (Typical 45ppm/°C). Can be scaled to any desired range.
