Reading display information, reading / writing all configuration settings and data log extraction.
Modbus RTU - RS485 2-wire, bus termination without resistor for low power solutions
USB communication incl. Ex d plug
Requires ¾”NPT or M25 side entry thread.
No communication, remote configuration possible with accessory cable ACE02.
1200 - 2400 - 4800 - 9600 - 9600HP - 19200 - 38400
• Differential total and/or flow rate
• Differential total and non-resettable accumulated total
• Total A forward flow
• Total B reverse flow
• Differential total can be reset to zero by pressing the CLEAR-key twice.
• Speedometer flowrate: differential, forward flow or reverse flow
• Current Day total, previous day total and 15 historical day totals
L, m3, US gal, igal, cf, Oil bbl, kg, ton, US ton, lb or none.
Total can be reset to zero.
According to selection for total
0:00 – 23:00, settable per whole hour
Running total, started at zero after the last contract hour
Fixed total, copied from current day total at the last contract hour
The last 15 previous day totals are stored and can be reviewed on the display
Current day total cannot be reset to zero.
According to selection for total.
Differential total, total A(forward flow) and total B (reverse flow)
Accumulated total cannot be reset to zero.
mL, L, m3, mg, g, kg, ton, US ton, US gal, igal, Oil bbl, lb, cf, rev, none, scf, nm3, nL or p.
20 blocks, each block is 5% of total span
/sec - /min - /hr - /day.
