Fluidwell E119-P Operation Manual

Page 58
FW-E115-P-M_v0203_03_EN.docx
[d] 2147
[h] 0x863
42148
day totals
1
R/W
uint16
0=hidden
1=operate
2=off
[d] 80
[h] 0x050
40081
LCD update
time
1
R/W
uint16
0= fast
1=1 sec
2=3 sec
3=15 sec
4=30 sec
5=off
[d] 67
[h] 0x043
40068
backlight
brightness
1
R/W
uint16
0=off
1=20%
2=40%
3=60%
4=80%
5=100%
[d] 58
[h] 0x03A
40059
bar graph
enable
1
R/W
uint16
0=disable
1=absolute
2=rate a
3=rate b
[d] 59
[h] 0x03B
40060
bar graph
range
2
R/W
uint32
0…9999999
Representation: unit, time, decimals depending on variables
48, 49, 50
Flowmeter
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 96
[h] 0x060
40097
flowmeter
signal – A
1
R/W
uint16
0=NPN
1=NPN LP
2=Reed
3=Reed LP
4=PNP
5=PNP LP
6=NAMUR
7=coil hi
8= coil lo
9=act 8.2V
10=act 24V
[d] 97
[h] 0x061
40098
flowmeter
signal – B
1
R/W
uint16
0=NPN
1=NPN LP
2=Reed
3=Reed LP
4=PNP
5=PNP LP
6=NAMUR
7=coil hi
8= coil lo
9=act 8.2V
10=act 24V
[d] 207
[h] 0x0CF
40208
Bi-
directional
1
R/W
uint16
0=disable
1=90°
2=270°
[d] 140
[h] 0x08C
40141
Calculate
1
R/W
uint16
0=differ
1=add
2=not
negative
[d] 254
[h] 0x0FE
40255
K-Factor
1
R/W
uint16
0=single
1=dual
[d] 1051
[h] 0x41B
41052
K-factor -
unit type
1
R/W
uint16
0=Hand
1=Volumetric
2=Mass
[d] 1050
[h] 0x41A
41051
K-factor -
unit
1
R/W
uint16
0=none
1=L
2= m
3
3=US GAL
4= I GAL
5=CF
6= OilBBL
7=kg
8=ton
9=lb
10=us ton
[d] 1046
[h] 0x416
41047
K-factor - A
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 1049: decimals K-factor A.
[d] 1049
[h] 0x419
41050
K-factor - A
decimals
1
R/W
uint16
0…6
[d] 1062
[h] 0x426
41063
K-factor - B
2
R/W
uint32
1...9999999
Representation: 0.000010…9999999
depending on variable 1065: decimals K-factor B.
[d] 1065
[h] 0x429
41066
K-factor
decimals - B
1
R/W
uint16
0…6
Analog output
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 112
[h] 0x070
40113
analog
output
1
R/W
uint16
0=disable
1=enable
[d] 113
[h] 0x071
40114
minimum
rate
2
R/W
uint32
0…9999999
Sign indicated by variable 125: sign for minimum rate.
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 125
[h] 0x07D
40126
sign for
minimum
rate
1
R/W
uint16
0= +
(positive)
1= -
(negative)
[d] 116
[h] 0x074
40117
maximum
rate
2
R/W
uint32
0…9999999
Sign indicated by variable 126: sign for maximum rate.
Representation: unit, time, decimals depending on variables
48, 49, 50
[d] 126
[h] 0x07E
40127
sign for
maximum
rate
1
R/W
uint16
0= +
(positive)
1= -
(negative)
[d] 124
[h] 0x07C
40125
Rate select
1
R/W
uint16
0=signed
1=absolute
2=rate A
3=rate B
[d] 119
[h] 0x077
40120
cut off
percentage
1
R/W
uint16
0...99
Representation: 0.0 – 9.9%
