Fluidwell E119-P Operation Manual

Page 59
FW-E115-P-M_v0203_03_EN.docx
[d] 120
[h] 0x078
40121
tune
minimum
output
1
R/W
uint16
0...9999
[d] 122
[h] 0x07A
40123
tune
maximum
output
1
R/W
uInt16
0...9999
[d] 127
[h] 0x07F
40128
filter
1
R/W
uint16
1...99
Pulse output
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 135
[h] 0x087
40136
Pulse mode
1
R/W
uint16
0=disable
1=not neg.
2=separate
3=signed
4=retransmit
[d] 128
[h] 0x080
40129
pulse time
width
1
R/W
uint16
0…9999
Representation: 0.001 – 9.999 sec
[d] 133
[h] 0x085
40134
pulse
quantity
decimals
1
R/W
uint16
0…3
[d] 130
[h] 0x082
40131
pulse per X
quantity
2
R/W
uint32
1...9999999
Representation: 0.000001…9999999
depending on variables 133, 32
Modbus communication
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 144
[h] 0x090
40145
speed
(baudrate)
1
R/W
uint16
0=1200
1=2400
2=4800
3=9600
4-9600HP
5=19200
6=38400
[d] 145
[h] 0x091
40146
modbus
address
1
R/W
uint16
1…247
[d] 146
[h] 0x092
40147
modbus
mode
1
R/W
uint16
0=off
1=RTU
2=ASCII
[d] 1271
[h] 0x4F7
41272
data bits
1
R/W
uint16
0=7 bits
1=8 bit
[d] 1272
[h] 0x4F8
41273
parity
1
R/W
uint16
0=none
1=even
2=odd
[d] 147
[h] 0x093
40148
delay
1
R/W
Uint8
delay between receiving a (valid) modbus command and
sending the response
0…255 ms
[d] 150
[h] 0x096
40151
index
1
R/W
uint16
used for indexed values 0…255
[d] 149
[h] 0x095
40150
index use
1
R/W
uint16
0=static
1=auto
increment
2=auto
decrement
[d] 25
[h] 0x019
40026
reboot
1
R/W
uint16
Returns 0 on read.
Write 0xA50F for unit restart
Write 0x5AF0 for factory settings
Others
PDU
ADDRESS
HOLDING
REGISTER
VARIABLE
NO.
REGISTERS
R/W
TYPE
VALUE / REMARKS
[d] 160
[h] 0x0A0
40161
model
number
1
R
uint16
0…9999
[d] 173
[h] 0x0AD
40174
model suffix
1
R
char
Representation: ASCII character
[d] 162
[h] 0x0A2
40163
firmware
version
2
R
uint32
0…999999
Representation: xx.xx.xx
[d] 165
[h] 0x0A5
40166
serial no
2
R
uint32
0…9999999
Representation: xxxxxxx
[d] 176
[h] 0x0B0
40177
local time
2
R/W
uint32
00:00:00 – 23:59:59
Representation: hh:mm:ss
Stored decimal: 23:59:59 = 235959d = 0x0003.99B7
[d] 168
[h] 0x0A8
40169
password
1
R
uint16
0…9999
[d] 139
[h] 0x08B
40140
keyboard
lock
1
R/W
uint16
0=disable
1=enable
[d] 170
[h] 0x0AA
40171
tag no
2
R/W
uint32
0...9999999
Representation: xxxxxxx
