Fluke 2638A - Thermistor Channels

Input and Channel Configuration
Channel Configuration 3
3-21
Thermistor Channels
Refer to Table 3-8 to configure a thermistor channel.
Table 3-8. Thermistor Channel Setup
1
2
3
4
5
6
hce022.eps
Item Function
 Thermistor function selection.
 Select the thermistor type. Types available: 2.252 kΩ, 5 kΩ, and 10 kΩ.

Set up the channel for a 2-wire measurement connection. See “Sense Input Configuration” on
page 3-3.
 Input a custom alpha-numeric label to help identify the channel (optional).
 Set an alarm for this channel (optional). See “HI and LO Channel Alarms” on page 3-30.
 Apply Mx+B scaling to the measurement (optional). See “Mx+B Scaling” on page 3-29.
