Fluke 2638A - Configure a Scan

Scan/Monitor, Record, and Data
Scan 4
4-5
Figure 4-2. Settling Time Delay Values (cont.)
Type and Range Time Delay
ACI all ranges 20 Hz filter 400 ms
ACI all ranges 200 Hz filter 100 ms
100 Ω 0 ms
1 kΩ 0 ms
10 kΩ 100 ms
100 kΩ 100 ms
1 MΩ 500 ms
10 MΩ 1 s
100 MΩ 1 s
Thermocouple all types 0 ms
PRT 400 Ω 0 ms
PRT 4 kΩ 100 ms
Thermistor 2 kΩ 500 ms
Thermistor 90 kΩ 500 ms
Thermistor 1 MΩ 1 s
Configure a Scan
Scans are configured in the Test Setup menu that is opened in the Channel Setup menu
(push
 then push ). This section contains information on each parameter in the
Test Setup menu to help configure the scan. Figure 4-3 shows the Test Setup menu.
