701/702
Users M
anual
94
Frequency Sourcing
FREQUENCY RANGES
MODELS 702 AND 701
COUNTS
1 YEAR
2 YEAR
2 Hz to 109.99 Hz
1
1
110 Hz to 1099 Hz
1
1
1.1 kHz to 10.9 k
Hz
1
1
11 kHz
to 50 kHz
2
2
Waveform
:
Squarewave, 50% duty
cycle
Amplitude
: 0 to 10V pk
Amplitude Accuracy
:
2 to 1099 Hz
: 3% of output + 0.05 V
1.1 to 10.9 kHz
: 10% of output + 0.05 V
11 to 50 kHz
: 30% of output + 0.05 V
Maximum Input Voltage:
30V dc
104
106
Table of Contents
Table of Contents
4
Introduction
12
Standard Equipment
15
Safety Information
21
Getting Acquainted with Your Calibrator
23
Input and Output Jacks
23
Keys
25
Display
28
Setting up the Calibrator
28
Using the Strap and Bail
28
Charging the Battery
31
Battery Life
32
Automatically Saving Battery Life
34
Using the Optional Battery Eliminator
34
Selecting the Display Language
35
Adjusting the Display Contrast
35
Setting up the Date and Time Display
35
Using the Backlight
36
Personalizing the Calibrator
37
Using Measure Mode
38
Measurement Ranges
38
Measuring Electrical Parameters
39
Testing Continuity
41
Measuring Pressure
41
Measuring Temperature
44
Using Thermocouples
44
Using Resistance-Temperature Detectors (Rtds)
47
Measurements in Percent of Scale
51
Damping Your Measurements
51
Using Source Mode
52
Sourcing Electrical Parameters
52
Simulating a 4 to 20 Ma Transmitter
54
Providing Loop Power
56
Sourcing Pressure
58
Simulating Thermocouples
61
Simulating Rtds
63
Sourcing in Percent of Scale
65
Stepping and Ramping the Output Value
65
Stepping the Output
65
Ramping the Output
66
Simultaneous Measure/Source
70
Generating "As Found" Test Data
73
Adjusting the Transmitter
77
As Left" Test Run
78
Calibrating a Process Instrument
73
Memory Operations
79
Saving Results
79
Reviewing Memory
80
Data Logging (Model 702 Only)
81
Observing Min and Max Measurements
83
Viewing the Task List (Model 702 Only)
83
Clearing Memory
84
Quick Guide to Applications
84
Communicating with a PC (Model 702 Only)
94
Maintenance
94
Replacing the Battery Pack
94
Internal Lithium Backup Battery
94
Cleaning the Calibrator
94
Calibration Data
95
Service Center Calibration or Repair
95
Replacement Parts
95
Specifications
97
DC Voltage Measurement
98
AC Voltage Measurement
99
DC Current Measurement
100
Resistance Measurement
100
Continuity Testing
101
Frequency Measurement
101
DC Voltage Output
102
DC Current Output
103
Resistance Sourcing
104
Frequency Sourcing
105
Temperature, Thermocouples
106
Temperature, Resistance Temperature Detectors
109
Loop Power Supply
110
Top and Bottom Limits of Ranges with Auto Range on
111
General Specifications
113
Index
