Fluke 702 User Manual

701/702
Users Manual
100
Top and Bottom Limits of Ranges with Auto Range On
RANGE, DC V MEASURE TOP OF RANGE BOTTOM OF RANGE
110 mV ±110.000 mV 0.000 mV
1.1 V ±1.10000 V ±0.10000 V
11 V ±11.0000 V ±1.0000 V
110 V ±110.000 V ±10.000 V
300 V ±300.00 V ±100.00 V
RANGE, DC V SOURCE
110 mV +110.000 mV -10.000 mV
1.1 V +1.10000V +0.10000 V
11 V +11.000V +1.1000 V
RANGE, OHMS MEASURE AND SOURCE
11 Ω 11.000 Ω 0.000 Ω
110 Ω 110.00 Ω 10.00 Ω
1.1 kΩ 1100.0 Ω 100.0 Ω
11 kΩ 11.000 kΩ 1.000 kΩ
RANGE, CURRENT MEASURE
22 mA +22.000 mA 0.000 mA

Fluke 702 Specifications

General

DC Current Range	0 to 24 mA
Accuracy	0.05% of full scale
Pressure Units	inH2O, psi, bar, mBar, kPa, kgcm2, cmH2O
Display	LCD
Loop Power	24 V DC
Operating Temperature	-10 °C to 55 °C
Storage Temperature	-40 °C to 60 °C
Warranty	3 years
