Documenting Process Calibrator
Introduction
3
Table 1. Summary of Source and Measure Functions
FUNCTION MEASURE SOURCE
v dc V 0 to ±300V 0 to 11V in V or mV units (10 mA max)
h ac V 0 to 300V rms, 20 Hz to 5 kHz No sourcing
h Frequency 1 Hz to 50 kHz, 110 mV to 300V rms 1 mV to 10V pk square wave, 2 Hz to 50 kHz
q Resistance 0Ω to 11 kΩ 0Ω to 11 kΩ
m dc Current 0 to 110 mA 0 to 22 mA (28V max)
q Continuity Beep and the word Short indicates
continuity
No sourcing
t Thermocouple E, N, J, L, K, T, U, B, R, S, or C
t RTD
Measure 2,3, or 4 wire.
Source 2 Wire.
100Ω Platinum (3926)
100Ω Platinum (385)
120Ω Nickel (672)
200Ω Platinum (385)
500Ω Platinum (385)
1000Ω Platinum (385)
10Ω Copper (427)
100Ω Platinum (3916)
p Pressure 14 modules ranging from 0 to 10” H
2
0
(2.5 kPa) to 0 to 10,000 psi (69,000
kPa)
Note
s Loop Power 24 or 28V (22 mA max)
Note: Use an external hand pump or other pressure source as a pressure stimulus for the source pressure function.
