Fluke QED 6 - Technical Specifications

QED 6
Users Guide
1-10
Specifications
The following are specifications for the Analyzer. Please contact your Fluke
Biomedical service representative for more information regarding the device
specifications.
General
Display.....................................................................2-line x 24-character LCD
supertwist alphanumeric
Power ......................................................................One 9 V Alkaline (Duracell MN1604 or
equivalent); 12 hours continuous
operation; low battery indication; 9 V
battery eliminator input.
Weight ....................................................................4.54 lb
Dimensions .............................................................26.67 x 24.13 x 10.16 cm
Environmental Operating Specs
Storage Temperature ..........................................-25 to 50 °C
Operating Temperature .......................................0 to 40 °C
Maximum Humidity..............................................90 % Relative Humidity
Output Power Measurement
Load Resistance......................................................50 Ω ±1 % non-inductance
(< 10 µH), 160 W
Range
1000 J..................................................................0-1000.0 J
100 J....................................................................0-100.0 J
Resolution................................................................0.1 J
Max. Vage
1000 J..................................................................5500 V
100 J....................................................................1750 V
Max. Current
1000 J..................................................................110 A
100 J....................................................................35 A
Measurement...........................................................1000 J: 66 ±5 V
Trip Levels...............................................................100 J: 20 ±5 V
Pulse Width .............................................................1-50 ms
Accuracy
1000 J Range ......................................................±2 % of reading
100-1000 J .......................................................... ±2 Js
100 J Range ........................................................±2 % of reading
±0.1 J
