Fluke QED 6 - Serial Port Wiring Configuration; Serial Cable Wiring Configuration

Operation
Remote Operation
2
2-37
Table 2-4. Serial Port Wiring Configuration
Pin Function
1 Unused
2 RX
3 TX
4 DTR
5 Unused
6 Unused
7 Unused
8 Serial
9 232 Ground
Use the Fluke serial cable to transfer data from the Analyzer serial port to any
IBM (or compatible) computer or printer. The Data Terminal Equipment
(DTE) wiring configuration is shown in Table 2-5.
Table 2-5. Serial Cable Wiring Configuration
Pin Function
1 Unused
2 TX
3 RX
4 RTS
5 CTS
6 DSR
7 232 Ground
8-25 Unused
The communications protocol is user-configurable, and the setup is performed
by software internal to the processor.
