Fluke QED 6 - Defibrillator Fire and ECG Performance Testing

QED 6
Users Guide
2-12
Fluke Biomedicals
fcf009.eps
Figure 2-6. QEDR Performance Tag
Note
The Analyzer continues to display the reading until the next
defibrillator pulse is fired.
Evaluating Ability to Fire
This test evaluates an automatic defibrillator for its ability to fire automatically
after recognizing ventricular fibrillation and / or ventricular tachycardia.
To test the ability of the defibrillator to fire automatically:
1. Attach the optional automatic defibrillator paddle adapters to the
Analyzer.
2. Connect the ECG patient leads to the Analyzer, as shown in Figure
2-7.
