Fluke QED 6 - Initial Setup and Powering On

Operation
Introduction
2
2-3
Introduction
The Analyzer uses a 2-line x 24-character LCD display and softkeys to
simplify operation. See Figure 2-1.
QED-6
DEFIBRILLATOR ANALYZER
STERNUM (-)
BATTERY / 9VDC RS-232 / 10101
ECG
V
C
LL
F
LA
L
RL
N
RA
R
DEFIB
APEX (+)
PACER
1000 j
100 j
SOFTKEYS
Menu Choice Line
Test Results Line
fcf014.eps
Figure 2-1. Analyzer Front Panel Display
