Fluke 19xB-19xC-2x5C
Service Manual
3-4
3.3 Final Assembly Parts
See Table 3-1 and Figure 3-1 for the Final Assembly parts.
Table 3-1. Final Assembly Parts
Item Description Ordering Code
1 Top case assembly (without LCD, without window/decal) 1638248
2 Display window/decal Fluke 192B
Display window/decal Fluke 192C
Display window/decal Fluke 196B
Display window/decal Fluke 196C
Display window/decal Fluke 199B
Display window/decal Fluke 199C
Display window/decal Fluke 215C
Display window/decal Fluke 225C
2042440
3402263
2042457
2042478
2042469
2042484
3402256
3402239
3 + 4 Keypad set (includes large & small keypad) 19x
(Lowest yellow key = RECORDER)
Keypad set (includes large & small keypad) 2x5
(Lowest yellow key = ANALYZE)
1638180
3402242
5 Keypad foil 1642199
6 Keypad support assembly 1638253
7 Display unit Color Fluke 192C, 196C, 199C, 215C, 225C
Display unit B/W Fluke 192B, 196B, 199B
Remark: The Display unit does not include the flat cable
1638230
2042528
Flat cable for display unit (both versions) 2042596
8 Display mounting frame assy 1668063
9 Input cover (including screws) 1285765
10 EJOT Pt screw 1284966
11 Main PCA unit; The Main PCA is only available to Fluke Service Centers
due to the programming that is necessary after installation.
-
12 Hang strap 1286041
13 Bottom case assembly (see note 2 below) 1285783
14 Combi-screw Torx M3x10 (screw + split spring) 1285046
15 Strap 1285923
16 Strap holder 1285938
17 Tilt stand (bail) 1285945
18 Combi-screw Torx M3x10 (screw + flat washer) 1285079
19 Bottom holster 1285752
20 Combi-screw Torx M3x10 (screw + flat washer) 1285079
21 Battery Pack (see note 3 below) BP190
22 Spacer M2.5x3 for Fan 1638770
23 Fan Assy 1638294
24 Screw M2.5x12, countersunk Torx for Fan 1639787
Note
The test tool contains a NiMH battery (item 21). Do not mix
with the solid wastestream. Spent batteries should be disposed
of by a qualified recycler or hazardous materials handler.
