Calibration Adjustment
5.6.9 Calculate Gain 5
5-17
Table 5-6. Ohm Gain Calibration Points
Cal Step UUT input Value (5500 NORMAL)
CL 0910 100 Ω
CL 0911 1 kΩ
CL 0912 10 kΩ
CL 0913 100 kΩ
CL 0914 1 MΩ
CL 0915 10 MΩ
5.6.9 Calculate Gain
1. Remove all test leads from the test tool inputs.
2. Press
to select calibration adjustment step CL 0920.
3. Press
to start the calibration.
4. Wait until the display shows the calibration status
:READY.
5. Continue at section 5.7
5.7 Save Calibration Data and Exit
Proceed as follows to save the calibration data, and to exit the Maintenance mode:
1. Remove all test leads from the test tool inputs.
2. Press
EXIT. The test tool will display:
Calibration data valid.
Save data and exit maintenance mode?
Note
Calibration data valid indicates that the calibration adjustment procedure
is performed correctly. It does not necessarily mean that the test tool meets
the characteristics listed in Chapter 2.
3. Press
YES to save and exit.
Note 1
After saving the calibration data, the calibration number and - date will be
updated if the calibration data have been changed and the data are valid.
The calibration number and - date will not change if:
- the calibration mode is entered and left without doing a calibration adjustment.
- only the contrast calibration adjustment (5.4) and/or the probe calibration is
done.
Note 2
If you press
NO ,the test tool returns to the calibration mode. You can
either calibrate the test tool again, or press
EXIT , YES to save and
exit.
