Fluke 19xB-19xC-2x5C
Service Manual
3-6
3.4 Main PCA Unit Parts
See Table 3-2 and Figure 3-2 for the main PCA Unit parts.
Table 3-2. Main PCA Unit Parts
Item Description Ordering Code
1 Shielding box assy (includes rubber spacer, see fig. 8-5) 1665767
2 Insulation foil 1285961
3 PT-Screw K35x8 1284975
4 Input connector unit 1285977
5 Sealing ring for power connector 1286052
6 Input attenuator shielding:
- METER channel top
- METER channel bottom
- SCOPE channel A top
- SCOPE channel B top
- SCOPE channel A&B bottom
1285989
1285992
1286007
1286018
1286029
7 Screw Torx M3x20 1285101
8 Shielding cover 1286034
9 Combi-screw Torx M3x10 (screw + split spring) 1285046
10 Hexagonal spacer M3x16.5 1285199
Note
The Scope channel A and B input attenuator top shieldings are provided with a
plate spring. The spring end is provided with heat conducting tape; it contacts
the C-ASIC’s N1000 and N1200, and transports the heat from the C-ASIC to the
shielding.
Do not bend the springs, keep the tape on the spring end free of dust, and put the
shielding on the correct position.
