Fluke Ti480 - Detailed Specifications: Imaging Performance; Imaging Performance Metrics; IR-Fusion and Camera Specs

Ti200, Ti300, Ti400, Ti450, Ti450SF6, Ti480
Users Manual
44
Detailed Specifications
Ti200 Ti300 Ti400 Ti450 Ti450SF6 Ti480
Temperature Measurements
Temperature Range (not
calibrated below -10 °C)
-20 °C to +650 °C -20 °C to +1200 °C
-20 °C to
+800 °C
Accuracy
±2 °C or 2 % (whichever is greater) at 25 °C ambient
[1]
Imagining Performance
Image Capture Frequency 9 Hz or 60 Hz refresh rate depending on model variation
Detector Resolution 200 X 150 240 X 180 320 X 240 640 X 480
Total pixels 30 000 43 200 76 800 307 200
SuperResolution NA
640 X 480 (307 200 pixels)
[1]
1280 X 960
Thermal Sensitivity (NETD)
≤0.075 °C at
30 °C target
temp (75 mK)
≤0.05 °C at 30 °C target temp
(50 mK)
≤0.03 °C at
30 °C target
temp (30 mK)
≤0.025 °C at
30 °C target
temp (25 mK)
≤0.05 °C at
30 °C target
temp (50 mK)
Infrared spectral band 7.5 μm to 14 μm (long wave)
Digital Zoom NA 2X, 4X
IR-Fusion Technology
Autoblend mode 100 %, 75 %, 50 %, 25 % IR plus full visible on camera
Picture-in-Picture 100 %, 75 %, 50 %, 25 % IR
Visual (Visible Light) Camera
Type Industrial performance 5.0 MP
Parallax alignment with standard
IR lens
From ∼60 cm (∼24 in) to infinity
Standard Infrared Lens
Field of View (H X V) 24 ° x 17 ° 34 ° x 24 °
Spatial Resolution (IFOV) 2.09 mRad 1.75 mRad 1.31 mRad 0.93 mRad
Minimum Focus Distance 15 cm (∼6 in)
IR-Fusion Autoblend Picture-in-Picture and Full screen
Optional 2X telephoto smart lens
Field of View (H X V) 12 ° x 9 ° 12 ° x 8.5 °
Spatial Resolution (IFOV) 1.05 mRad 0.87 mRad 0.65 mRad 0.33 mRad
Minimum Focus Distance 45 cm (∼18 in)
IR-Fusion blending Picture-in-Picture and Full screen
Optional 4X telephoto smart lens
Field of View (H X V) 6.0 ° x 4.5 °
NA
Spatial Resolution (IFOV) 0.53 mRad 0.44 mRad 0.33 mRad
Minimum Focus Distance 1.5 m (∼5 ft)
IR-Fusion blending Picture-in-Picture and Full screen
Optional wide-angle smart lens
Field of View (H X V) 46 ° x 34 ° 48 ° x 34 °
Spatial Resolution (IFOV) 4.19 mRad 3.49 mRad 2.62 mRad 1.31 mRad
Minimum Focus Distance 15 cm (∼6 in)
IR-Fusion blending Full screen
