Removing a knob:
Remove the pot cover by slowly pulling on it, it
should come off without much effort.
1. Remove the 4 screws located on the back of
the system and remove the back cover.
2. Follow the knobs wire and disconnect it form
the board.
3. Gently remove the knob cap by pulling it up.
4. Remove the nut holding the knob in place.
5. Remove knob.
9.2 Activate Switch/Knob
Open the system menu, navigate to "Aux Switches" and press the "OK" key. Use the "OK" key to change
switch/knob, then use the "UP" or "DOWN" keys to turn the switch on.
The switch will now be available in the "Assign Switches" menu.
