Flymaster GPS M User Manual v. 1.0
Objects (Graphical Elements)
Graphical elements are characterized by providing information in a graphical way. Most
of the graphical elements have fixed dimensions, although their position can be altered.
Battery
The Battery Element provides a graphical indication of the current battery level. This
element has fixed dimensions.
Volume indicator
e indicator element provides a graphical indication of the current volume level. This
element has fixed dimensions.
GPS
The GPS Element provides graphical indication about the current GPS signal quality.
Basically, the lower the PDOP value (position dilution of precision), the more accurate
calculations are for determining position. Values bellow 3.0 are fairly accurate. The Pdop
values can be seen in info page (select settings icon without pressing ENTER)
Vario
When the GPS M detects that the pilot is climbing, a black bar starts to grow on the left,
from the bottom of the scale to the top ,with 0.1 m/s increments. The same bar grows on
the right, from the top of the scale to the bottom, if sinking is detected.
