Flymaster GPS M User Manual v. 1.0
Default Pages
GPS M allows you to design up to 8 pages in portrait mode and 8 in landscape mode, using the Flymaster
Instrument Manager. In flight you can change pages manually using the ENTER button. On the following
pages we will show which pages Flymaster designed and which will be default to the instrument.
The description of each data field is available in this user manual in the section “available data fields”.
The description of each object is available in this user manual in the section “objects”.
Page 1 – Main Page
1 – Altitude
2 – Wind arrow
3 – Speed
4 – Current glide ratio
5 – Altitude gain
6 – Max. Climb
7 – Vario
8– Navigation wheel
9 – Max. Sink
10 –Active waypoint
11 – Dist. Edge
12 – Flight duration
13 – Time
14 – Glide ratio to next
15 – Dist. Thermal
1
2
4
3
7
6
5
8
9
10
11
15
14
13
12
