Page 38
Flymaster GPS M User Manual v. 1.0
Roads
Wind Arrow
When used in a layout an arrow is draw showing the wind direction relative to the pilot
direction (direction the wind is coming from). For example, if the pilot is facing the wind
then the arrow points south (bottom of the screen). Cantered over the arrow is a circle in
which a number is displayed showing the wind speed. In the example above the wind is
blowing from South. Both, the wind speed, and direction, value can be seen in a data fields.
