30
Installation and Operation Manual
SystemsSystems
2001 and 2002
Normal Operation Summary
How to
Action
6. Press the SELECT button (grey
upper-right button) until the LED
lamp below the TOTAL FOAM
label is illuminated. The total
amount of foam concentrate
used will be displayed. Reset this
value to zero by pressing the ▼
and ▲
buttons at the same time.
8. Turn the FoamPro system off.
Display
7. If on, press the FOAM button, the
foam injection will stop. Press the
SELECT button (grey upper-right
button) until the LED lamp below
FLOW is illuminated. The water
flow rate through the foam
discharge(s) will be displayed
whether foam is being pumped
or not.
8. Turn the apparatus Master or
Battery switch off. The system
can also be turned off by using
the circuit breaker switch on the
valve driver box.
6. Read the total amount of foam
concentrate used.
7. Read water flow without foam
injection.
NOTE: Any of these changes can
be made at anytime during, before,
or after water is flowing.
