MX-4 USER GUIDE CHAPTER 7
72
Force Field Freeze
The Force Field Freeze option lets you specify whether you want the MX-4 to perform a frame or
field freeze. This option works in conjunction with the Freeze feature (refer to “Freeze” on
page 78).
Frame Freeze produces best quality, but it might produce a jittering effect when trying to freeze
objects in motion. In such cases, use a Field Freeze.
Field Freeze – The MX-4 freezes only every other line of the image. This produces a fast
freeze, but image quality degrades somewhat. To use Field Freeze, set the Force Field Freeze
option to 1.
Frame Freeze – The MX-4 freezes every line in the image. The freeze takes slightly longer,
but the image quality matches the original because it uses all of the video signal. To use Frame
Freeze, set the Force Field Freeze option to 0 (zero).
GPI Out Mode
This setting determines whether the MX-4 provides a GPI output to an external device, such as a
character generator, thereby allowing you to trigger an external event based on an action from the
MX-4. Set the value to 0 (zero) to use the MX-4 with an edit controller. Set the value to 1 to enable
GPI output to trigger a character generator, such as the Videonics TitleMaker.
CAUTION
The MX-4 also accepts values 2 through 4 for this option. However, using any of these values
might cause your equipment to malfunction and should not be used.
Refer to “Using a GPI Device” beginning on page 118 for relevant information.
Comb Filter
This option can be used in some cases to affect the quality of the video coming from an input
source. Normally, you should leave this set at the default – 1 or On. Change it only if asked to do so
by a FOCUS Enhancements Customer Support Representative.
Dual Monitor Mode
This lets you specify whether you want the MX-4 to run the selected transition on both the preview
and program monitor at the same time with a setting at 0. As an alternative, you can keep the pre-
view screen constant while the transition takes place on the program monitor only with a setting at
1.
7.5 IRE Pedestal
NTSC Video equipment commonly uses one of two black level settings:
• 7.5 IRE – The traditional black, which is the MX-4 default setting.
• 0 IRE – A darker black level used in Japan.
To use the darker black (0 IRE) for the MX-4 background and border colors, set Pedestal to 0
(zero).
If you are working with equipment that requires 7.5 IRE, set Pedestal to 1.
NOTE
This option is not available on PAL versions of the MX-4.
