CHAPTER 8
PIPS
PIP (Picture-In-Picture) provides a way to combine images on the same screen. For exam-
ple, one image appears inside a small rectangle, and the other image fills the remainder of
the screen as shown by Single PIP, above.
You can freeze the background or foreground, or make either one a solid color.
You can create Single PIP configurations where two images appear on the screen at the
same time. You can also create Multi-PIP configurations where up to four images appear on
the screen at the same time. Single PIP and Multi-PIP work differently.
PIP images consist of a tile (the video image) and a mask (the window or shape through
which the tile shows).
Multi-PIPSingle PIP
With the MX-4 you can
easily produce single
and multiple
Picture-in-Picture
displays.
