Power Connector
The MX-4 package contains the required transformer and power cord for the unit.
To connect the power cord and transformer:
1 Connect the female plug on the power cord into the male socket on the transformer.
2 Connect the male plug on the power cord to a suitable power outlet.
3 Connect the power adapter plug on the transformer cord into the power connector on the MX-
4 rear panel.
4 Turn the MX-4 power switch (located on the right side of the unit) to the ON position.
CABLES AND ADAPTERS
To connect video devices to the MX-4 you need specific types of cables. You might also need one
or more adapters, depending on your equipment.
Look closely at the jacks on the MX-4 rear panel and note that they accept RCA Composite or S-
Video cables.
Before connecting any device to the MX-4, make sure the cable you are using has the right type of
fitting for the jack you intend to use.
Power
Adapter
Plug
Male
Plug
Male Socket Female Plug
Transformer Power Cord
WARNING
USE ONLY THE POWER CORD AND TRANSFORMER PROVIDED IN THE PACKAGE. DO NOT
USE THIS POWER CORD AND TRANSFORMER WITH ANY OTHER EQUIPMENT. FAILURE TO
OBSERVE THESE CONDITIONS CAN DAMAGE YOUR EQUIPMENT AND VOID YOUR
WARRANTY.
RCA S-Video
Composite (Y/C)
