REDNET CONTROL 2
RedNet Control 2 is Focusrite’s customisable software application for controlling and configuring
RedNet, Red and ISA range of interfaces. Graphical representation for each device shows: control
levels, function settings, signal meters, signal routing and mixing – as well as providing status
indicators for power supplies, clock and the primary/secondary network connections.
REDNET R1 GUI
Graphical configuration for RedNet R1 is separated into five pages:
• Source Groups • Talkback
• Monitor Outputs • Cue Mixes
• Channel Mapping
Selecting a Red Device to Control
Use the drop-down in the header of any GUI page to select a device
Source Groups
The Source Groups page is used to configure to the eight input groups and to assign an audio source
to each input channel.
Continued...
