Focusrite Rednet R1 - Input Channel and Source Selection

14
Input Channel Configuration
Click the drop-down below each Source Group button to assign its channel
configuration.
Two options are available:
• Presets – Select from the list of predefined channel configurations:
- Mono - 5.1.2
- Stereo - 5.1.4
- LCR - 7.1.2
- 5.1 - 7.1.4
- 7.1
Presets allow the user to quickly setup the Source Groups (and Monitor Outputs) pages without
being required to enter individual cross-points on the ‘Channel Mapping’ page.
The defined presets auto-fill the mapping table with predefined routing and mix coefficients, so
that all fold-ups and fold-downs are done automatically, ie., a 7.1.4 source will be automatically routed
to a 5.1 Output speaker conguration.
• Custom – Allows individual named formats and channel mapping table configurations.
Input Source Selection
The audio source assigned to each channel in a group is selected using its drop-down:
The list of sources available will depend on the device being controlled:
- Analogue 1-8/16 Red device dependent
- ADAT 1-16
- S/PDIF 1-2
- Dante 1-32
- Playback (DAW) 1-64
• Channels can be renamed by double-clicking on their current name.
Source Groups . . .
