Folger Tech FT-5 - Page 29

FT-5 User Manual Page 28
3. Take the M8 leadscrew and insert it through
the KFL8 located on the bottom of the frame.
You may need to loosen the set screws on the
KFL8. Take one of the 20T 8mm bore pulleys
and one of the GT2 belts and insert them on
the threaded rod.
4. Thread the threaded rod through the bed
plate and all the way to the KFL8 on the middle
mounting bracket.
5. Tighten the set screws on the bottom KFL8.
