Folger Tech FT-5 - Electronics Check List

FT-5 User Manual Page 68
ELECTRONICS CHE CK LIST
The goal of this section is to make sure all of the electronics are plugged in correctly. It is important that you
follow these steps and do not power up the printer before being instructed to do so.
1. The power coming into the board should be
Black, Red, Black, Red for the 2 big green
plugs on the MKS board.
2. The thermistor wires should be plugged into
the 1
st
and 2
rd
connector. The top one should
be the hot end and the bottom should be the
heated bed.
