FT-5 User Manual Page 5
FOLGER TECH FT -5 HARDWARE
Item
ID
Total
Supplied
Description
Item ID
Total
Supplied
Description
A
56
M3 Nylock Nut
S
12
M4 Nylock Nut
B
26
M3 T-nut
T
8
M4x8 Screw
C
12
M3 Flat Washer
U
4
M4x10 Screw
D
19
M3 Square Nut
V
8
M4x16 Screw
E
32
M3x8 Screw
W
16
M4x20 Screw
F
14
M3x10 screw
X
2
M5 Nylock Nut
G
12
M3x12 Screw
Y
164
M5 T-nut
H
48
M3x16 Screw
Z
164
M5x10 Screw
I
6
M3x20 Screw
AA
6
Small Cable Clamp
J
12
M3x30 Screw
AB
4
Large Cable Clamp
K
6
M3x40 Screw
AC
15
Black Zip Tie
L
4
M3x45 Screw
AD
10
Printed Estop Button
M
8
M3 Thumb Screw
AE
1
Printed Endstop mount
N
4
L Bracket
AF
4
Binder Clips
O
8
Bed Spring
AG
3
Belt Tensioner Spring
P
4
Med Nylon Spacers
AH
8
M4 Set Screw
Q
8
M4 set screw
AI
2
M3 Set Screws
R
28
M4 T-nut
AJ
2
Fuse
FOLGER TECH FT -5 LASER CUT PARTS
Item
ID
Total
Supplied
Description
Item ID
Total
Supplied
Description
FT1
13
Corners (4 Bolts)
FT15
1
The Hatch
FT2
8
Corners (5 Bolts)
FT16
1
Bed Plate
FT3
1
Idler Top (4 Bolts Right)
FT17
1
Upper Panel (FR w/ Cable)
FT4
1
Idler (2 Bolts)
FT18
1
Upper Panel (FL)
FT5
1
Y-Belt
FT19
1
Electronics Box (MKS +PS)
FT6
1
Y Endstop Mount
FT20
1
Electronics Box Side (power)
FT7
1
Motor Right
FT21
1
Electronics Box (USB)
FT8
1
Motor/Right/Middle
FT22
1
Electronics Box (Honey Air Vent)
FT9
1
Motor/Right/Top
FT23
1
Bottom Panel (500x500)
FT10
1
Idler (7 Bolts)
FT24
1
Spool Holder (Circle)
FT11
1
Extruder Front Plate
FT25
1
LCD Panel
FT12
1
Extruder Back Plate
FT26
1
Idler Top (4 Bolts Left)
FT13
2
Extruder Chain Mount
FT27
1
Extruder (H)
FT14
1
Extruder (H no holes)
FT28
1
Spool Holder (T-Hut)
