FT-5 User Manual Page 36
9. Place the slider rail on top of the 2020 beam.
The rail should butt up to the idler (2 bolt).
Secure the slider rail in place.
Note: If the screws were not installed on the slider
rail, refer to phase 7 step 1 for details.
10. Put the stepper motor onto the 2020 beam
and butt it up to the rail. The limit switch
should be on the inside. Lock this in place
using the two M5 screws.
