FT-5 User Manual Page 66
34. Plug in the three limit switches into the board.
From right to left it’s Z min, Y min, X min.
35. Plug in the two thermistor wires into the board.
The middle is the heated bed and the bottom is
the hotend thermistor.
36. Insert the heatbed wires and the hotend heater
wires into the board. The color orientation of
these two do not matter.
37. Add the heatsinks to the five stepper motor
drivers. Peel off the paper on the bottom and
stick them on top of the main chip of the driver.
Power should be off to the machine for this step!!
