Circuits protectedFuse ratingFuse
Not used-9
Power seat movement -
driver's
30 A10
Power seat movement -
passenger's
30 A11
Not used-12
Not used-13
Powertrain control module
battery positive
5 A14
Powertrain control module
power relay
40 A15
Power supply for
passenger's junction box
40 A16
Not used-17
Not used-18
Ignition tachograph5 A19
Heated mirror, windshield
relay
5 A20
Not used-21
Ignition non start related to
passenger's junction box
15 A22
Front and rear air condi-
tioning control
7.5 A23
Headlamp leveling5 A24
Not used-25
Not used-26
Heated seats20 A27
Not used-28
Rear view camera, lane
keeping system, electric
mirror
10 A29
139
Tourneo Custom/Transit Custom (TTF)
Fuses
