Ford TRANSIT CUSTOM - Removing a Headlamp

2. Remove the wiper blade.
3. Install in the reverse order.
Note: Make sure that the wiper blade locks
into place.
Rear Window Wiper Blades
1. Lift the wiper arm.
2. Position the wiper blade at right angles
to the wiper arm.
3. Disengage the wiper blade from the
wiper arm.
4. Unhook the wiper blade from the wiper
arm.
5. Slide the wiper blade to the side.
6. Remove the wiper blade.
7. Install in the reverse order.
Note: Make sure that the wiper blade locks
into place.
REMOVING A HEADLAMP
WARNING
Switch the lamps and the ignition off.
Failure to do so could result in
serious personal injury.
153
Tourneo Custom/Transit Custom (TTF)
Maintenance
