Towing Equipment Dimensions
Dimension in inches (mm)Dimension descriptionItem
46.3 (1176)Wheel center - end of tow ballA
16.6 (421)Center of tow ball - side memberB
33.2 (842)Inner side of side memberC
18.7 (476)Center of tow ball - center 1.attachment pointD
21.7 (551)Center of tow ball - center 2.attachment pointE
182
Tourneo Custom/Transit Custom (TTF)
Capacities and Specifications
