Circuits protectedFuse ratingFuse
Not used.-F28
Not used.-F29
Cooling fan 1.40AF30
Cooling fan 2.40AF31
Windshield dual wiper motors.60AF32
Start-Stop auxiliary water pump.20AF33
Not used.-F34
Powertrain control system supply.15AF35
Sensor NOXI 2.15AF36
Volume Control Valve.7.5AF37
Mass air flow sensor.7.5AF38
Diesel pump vaporizer.15AF39
Circuits switchedRelay
Ignition.R1
Starter motor.R2
Rear window wiper.R3
Not used.R4
Cooling fan.R5
Windshield wiper - on and off.R6
Windshield wiper - low and high speed.R7
Not used.R8
Not used.R9
Air conditioning clutch.R10
Fuel vaporizer system glow plug.R11
Fuel injection pump.R12
All-wheel drive pump.R13
146
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Fuses
