Ford Transit - Vehicle Identification Plate

Long Wheelbase Extended Frame
in (mm)Dimension descriptionMeasurement
61.4 (1,560)wheel center – end of tow ballA
16.5 (418)Center of tow ball - side memberB
32.9 (836)Inner side of side memberC
9.3 (237)Center of tow ball – center 1.attachment pointD
13.5 (343.5)Center of tow ball – center 2.attachment pointE
Extra Long Wheelbase Extended Frame
in (mm)Dimension descriptionMeasurement
78.0 (1,982)wheel center – end of tow ballA
16.5 (418)Center of tow ball - side memberB
32.9 (836)Inner side of side memberC
9.3 (237)Center of tow ball – center 1.attachment pointD
13.5 (343.5)Center of tow ball – center 2.attachment pointE
VEHICLE IDENTIFICATION
PLATE
Note: Your vehicle identification plate
design may vary to that shown.
Note: The information shown on your
vehicle identification plate is dependent
upon market requirements.
207
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Capacities and Specifications
