Ford Transit - Single Chassis Cab; Double Chassis Cab

Single Chassis Cab
Short Medium and Long Wheelbase
in (mm)Dimension descriptionMeasurement
46.4 (1,178)wheel center – end of tow ballA
16.5 (418)Center of tow ball - side memberB
32.9 (836)Inner side of side memberC
9.3 (237)Center of tow ball – center 1.attachment pointD
13.5 (343.5)Center of tow ball – center 2.attachment pointE
Long and Extra Long Wheelbase Extended Frame
in (mm)Dimension descriptionMeasurement
85.2 (2,165)wheel center – end of tow ballA
16.5 (418)Center of tow ball - side memberB
32.9 (836)Inner side of side memberC
9.3 (237)Center of tow ball – center 1.attachment pointD
13.5 (343.5)Center of tow ball – center 2.attachment pointE
Double Chassis Cab
Short Medium and Long Wheelbase
in (mm)Dimension descriptionMeasurement
46.4 (1,178)wheel center – end of tow ballA
16.5 (418)Center of tow ball - side memberB
32.9 (836)Inner side of side memberC
9.3 (237)Center of tow ball – center 1.attachment pointD
13.5 (343.5)Center of tow ball – center 2.attachment pointE
