Circuits protectedFuse ratingFuse
Front fog lamps.15AF8
Right-hand high beam.10AF9
Left-hand high beam.10AF10
Right-hand exterior lamps.
25AF11
Left-hand side lamps.
Battery backup sounder.
20AF12
Anti-theft alarm horn.
On-board diagnostic.
15AF13
Battery saver.
Turn signal indicator.25AF14
Left-hand exterior lamps.
25AF15 Right-hand side lamp.
Central high mounted brake lamp.
Audio unit.
20AF16
Navigation unit.
Instrument panel cluster.
7.5AF17
Heater control.
Headlamp switch module.
10AF18
Steering wheel module.
Front control/display interface module.5AF19
Ignition passive anti-theft system.5AF20
Accessory relay.3AF21
CHANGING A FUSE
WARNINGS
Do not modify the electrical system
of your vehicle in any way. Have
repairs to the electrical system and
the replacement of relays and high current
fuses carried out by an authorized dealer.
Switch the ignition and all electrical
equipment off before attempting to
change a fuse.
WARNINGS
Always replace a fuse with one that
has the specified amperage rating.
Using a fuse with a higher amperage
rating can cause severe wire damage and
could start a fire.
153
