Ford Transit - Motorhome Chassis

Motorhome Chassis
Medium Wheelbase
in (mm)Description
209.5 (5,321)Overall length
108.1 (2,746)97.4 (2,474)Overall width including standard or wide
exterior mirrors
87.1 (2,212)Overall height (measured at curb weight)
129.9 (3,300)Wheelbase
68.2 (1,732)Front track
68.6 (1,743)Rear track
Long Wheelbase
in (mm)Description
235.2 (5,975)Overall length
108.1 (2,746)97.4 (2,474)Overall width including standard or wide
exterior mirrors
86.8 (2,205)Overall height (measured at curb weight)
147.6 (3,750)Wheelbase
68.2 (1,732)Front track
68.6 (1,743)Rear track
Long Wheelbase Extended Frame
in (mm)Description
235.2 (5,975)Overall length
108.1 (2,746)97.4 (2,474)Overall width including standard or wide
exterior mirrors
86.6 (2,199)Overall height (measured at curb weight)
203
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Capacities and Specifications
