Front Airbag Warning Lamp
If it fails to illuminate when you
start your vehicle, continues to
flash or remains on, this
indicates a malfunction. Have your vehicle
checked by an authorized dealer
immediately.
Front Fog Lamp Indicator
It will illuminate when you switch
the front fog lamps on.
Frost Warning Lamp
WARNING
Even if the temperature rises to
above +39ºF (4ºC) there is no
guarantee that the road is free of
hazards caused by inclement weather.
It will illuminate when the
outside air temperature is 39ºF
(4ºC) or below.
Glow Plug Indicator
If it illuminates, wait until it
extinguishes before starting.
Headlamp Indicator
It will illuminate when you switch
the headlamp low beam or the
side and tail lamps on.
High Beam Indicator
It will illuminate when you switch
the headlamp high beam on. It
will flash when you use the
headlamp flasher.
Hill Start Assist Indicator
It will illuminate when the
system is not available.
Note: Not available on all instrument
clusters.
Ignition Warning Lamp
If it illuminates when driving, this
indicates a malfunction. Switch
off all unnecessary electrical
equipment. Have your vehicle checked by
an authorized dealer immediately.
Lane Departure Warning Indicator
It will illuminate when you switch
the system off.
It will illuminate when the
system is not available and may indicate
a system malfunction. Have your vehicle
checked by an authorized dealer as soon
as possible.
Low Fuel Level Warning Lamp
If it illuminates, refuel as soon as
possible.
Message Center Indicator
It will illuminate when a new
message is stored in the
information display. It will be red
or amber in color depending on the severity
of the message and will remain on until the
cause of the message has been rectified.
See Information Messages (page 69).
