Oil Pressure Warning Lamp
WARNING
Do not resume your journey if it
illuminates despite the level being
correct. Have your vehicle checked
by an authorized dealer immediately.
If it stays on after starting or
illuminates when driving, this
indicates a malfunction. Stop
your vehicle as soon as it is safe to do so
and switch the engine off. Check the engine
oil level. See Engine Oil Check (page 158).
Over Speed Warning Indicator
It will illuminate when your
vehicle exceeds a set speed.
Rear Fog Lamp Indicator
It will illuminate when you switch
the rear fog lamps on.
Safety Belt Minder Warning Lamp
It will illuminate and a chime will
sound to remind you to fasten
your safety belt. See Safety
Belt Minder (page 26).
Shift Indicator
It will illuminate when you are
recommended to shift up or
down from the selected gear.
Stability Control Indicator
It will illuminate for a short
period of time when you switch
the ignition on. If it illuminates
when you are driving, this indicates a
malfunction. During a malfunction, the
system turns off. Have your vehicle
checked by an authorized dealer as soon
as possible.
Note: While driving, it flashes when the
system is operating.
Stability Control Off
It will illuminate when you switch
the system off. It will go out
when you switch the system
back on or when you switch the ignition
off.
Start-Stop Indicator
It will illuminate when the engine
has automatically stopped. It will
flash to inform you when the
engine needs to restart. See
Auto-Start-Stop (page 99). See
Information Messages (page 69).
Low Tire Pressure Warning
Indicator
It will illuminate if the tire
pressure in one or more tires is
below the correct pressure. See
Tire Pressure Monitoring
System (page 182).
61
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Instrument Cluster
