Ford Transit - Instrument Cluster; Gauges; Information Display

GAUGES
Odometer, tripmeter, distance to empty and Information display. See
Information Displays (page 63).
A
Speedometer.B
Engine coolant temperature gauge.C
Tripmeter reset and distance to empty toggle button.D
Fuel gauge.E
Tachometer.F
Information Display
Odometer
Registers the distance your vehicle has
traveled.
Tripmeter Reset and Distance to Empty
Press the button to change between the
tripmeter and distance to empty
information. Press and hold the button to
reset the tripmeter.
Trip Computer
See Trip Computer (page 68).
Outside Air Temperature
Shows the outside air temperature.
57
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Instrument Cluster
