Ford Transit - Bulb Specification Chart; Sun Visor Mirror Lamp

3. Remove the bulb.
Vehicles without Interior Sensors
1. Carefully remove the lamp.
2. Turn the bulb holder counterclockwise
and remove it.
3. Remove the bulb.
Sun Visor Mirror Lamp
1. Carefully remove the lamp.
2. Remove the bulb.
BULB SPECIFICATION CHART
Exterior Lamps
Power (watt)SpecificationLamp
5W5WBody side marker lamp
21/5P21/5WBrake and tail lamp
16W16WCentral high mounted brake lamp
5W5WChassis cab rear marker lamp
55H1Cornering lamp
21PY21WFront direction indicator lamp
55H11Front fog lamp
170
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Maintenance
