Ford Transit - Page 154

Body Control Module Fuse Box
Circuits protectedFuse ratingFuse
Central locking system 2.15AF1
Central locking system 1.15AF2
Ignition switch.15AF3
Parking assist control module.5AF4
Rain sensor module.5AF5
Windshield washer pump.15AF6
Exterior mirrors.7.5AF7
152
Transit (TTG) Vehicles Built From: 19-06-2014, Vehicles Built Up To: 31-12-2014, EK3J-19A321-AKA (CG3612en) enGBR, Edition date: 04/2014, First Printing
Fuses
